PSG 1712 C
Cascadable multiswitch for distribution of 16 SAT IF polarisations and terrestrial signals.
- Brand:
Polytron
-
Code: PSG 1712 C
Available
| Type | PSG 1708 C | PSG 1712 C | PSG 1716 C |
| Article no. | 9268220 | 9268230 | 9268240 |
| Inputs | 16 SAT, 1 TERR | ||
| Outputs | 8 | 12 | 16 |
| Through loss TERR 40-862 MHz | 4 dB | 4 dB | 4 dB |
| Through lossВ SAT 950-2150 MHz | 5 dB | 5 dB | 5 dB |
| Tap lossВ Terr. 40-862 MHz | 24 dB | 24 dB | 27 dB |
| Tap lossВ SAT 950-2150 MHz | 3 dB | ||
| Switching commands | 14 V / 18 V / 0/22 kHz / DiSEqC 2.0 | ||
| IsolationВ Horz. / Vert. | > 28 dB | ||
| IsolationВ SAT / Ter. | > 30 dB | ||
| Input level max. | SAT: 95 dBВµV ; TERR: 95 dBВµV | ||
| Power consumption per receiver | 50 mA | ||
| LNB supply | max. 2400 mA | ||
| Operation temperature | -20...+50 В°C | ||
| Dimensions (W x H x D) [mm] | 370 x 128 x 54 | 370 x 209 x 54 | 370 x 209 x 54 |
