| Technical data | ||||||
| Type | SF 109-862 | SF FM / K5-8 | SF K2-S25 | SF K2-S38 | SF K2-K53 | SF K2-K61 |
| Article no. | 2564244 | 2564246 | 2561000 | 2561300 | 2564220 | 2564252 |
| TV pass range | S2-K69 | UKW/K5-8 | K2-S25 | K2-S38 | K2-K53 | K2-K61 |
| TV-rejection range | S4-S8 / K10-K69 | K2-4/S3-S9/K10-69 | S27-K69 | K21-K69 | K57-K69 | K65-K69 |
| Rejection loss | > 40 dB | > 40 dB | > 40 dB | > 40 dB | > 40 dB | > 40 dB |
| Separation channels | 100-108 MHz ≥ 25 | 67-86 MHz S2/S10/K9 | S26 | S39/S40 | K54-K56 | K62-K64 |
| TV through loss | ≤ 2 | |||||
| Screening factor | Class A | |||||
| Dimensions (W x H x D) | 70 x 21 x 21 mm | 62 x 47 x 20 mm | ||||
| Weight | 0,09 kg | 0,08 kg | ||||
