Channel insertion combiner
Combines a UHF-channel with an existing distribution network. 1 channel + remaining (4-862 MHz).
- Brand:
Polytron
-
Code: ESB 3-R
Available
| Technical data | |||
| Type | ESB 1-R | ESB 2-R | ESB 3-R |
| Article no. | 2342010 | 2342020 | 2342030 |
| Input 1 | K21-32 | K33-44 | K45-K54 |
| Input 2 | 4-862 MHz | ||
| Through loss | < 5 dB ; 4-862 MHz: < 1 dB | ||
| Rejection loss | > 12 dB ; В± 16 MHz: > 20 dB | ||
| Frequency at the output | 4 - 862 MHz | ||
| Amplitude frequency response | 4-862 MHz: 1 dB | ||
| Dimensions | 46 x 64 x 21 mm | ||
| Weight | 0,08 kg | ||
